Concrete Pre-Pour Inspection Checklist
Creating a comprehensive concrete pre-pour inspection checklist using eAuditor Audits & Inspection involves identifying key areas that need to be reviewed before pouring concrete. The checklist ensures all conditions are met for a successful concrete pour. Below is a guide on how to structure your checklist in eAuditor Audits & Inspection:
Concrete Pre-Pour Inspection Checklist
1. Project Details
- Project Name
- Location
- Inspection Date
- Inspector Name
- Weather Conditions
- Temperature
2. Formwork
- Formwork Stability
- Securely brace and stable the formwork .
- Are all connections tight and secure?
- Formwork Dimensions
- Are the formwork dimensions correct as per drawings?
- Check the formwork for squareness and levelness.
- Formwork Cleanliness
- Is the formwork free from debris and contamination?
- Treat the formwork with a release agent.
3. Reinforcement
- Rebar Installation
- Are rebar sizes and spacing according to the design specifications?
- Is the reinforcement free from rust, oil, or other contaminants?
- Rebar Ties and Supports
- Are all rebar ties secure?
- Are all rebar supports in place and adequately spaced?
- Clearances
- Are the required clearances between rebar and formwork maintained?
- Are corner bars and lap splices properly installed?
4. Embedded Items
- Placement of Embedded Items
- Properly position and secure all embedded items (e.g., anchor bolts, sleeves, conduits).
- Are embedded items clean and free from contaminants?
- Alignment and Elevation
- Align all embedded items and keep at the correct elevation.
5. Subgrade and Base Preparation
- Subgrade Condition
- Properly compact the subgrade.
- Is the subgrade free from standing water, mud, or debris?
- Base Material
- Compact and keep the base material in place as per specifications.
- Is the thickness of the base material adequate?
6. Joints and Joint Materials
- Expansion and Control Joints
- Are expansion and control joints in the correct locations and as per design?
- Are joint fillers and sealants in place and properly installed?
- Isolation Joints
- Install isolation joints where required (e.g., around columns)?
7. Utilities and Drainage
- Utility Conduits and Piping
- Are all utility conduits and piping properly placed and protected?
- Is there adequate coverage of concrete over conduits and piping?
- Drainage
- Properly grade the site for drainage?
- Are drainage systems installed and operational?
8. Access and Safety
- Site Access
- Is there clear and safe access for concrete delivery?
- Remove any obstruction.
- Safety Measures
- Are all necessary safety barriers and signs in place?
- Equip workers with proper PPE.
9. Quality Control and Documentation
- Mix Design Verification
- Has the concrete mix design been approved?
- Is there a copy of the mix design on site?
- Batching and Delivery
- Are concrete delivery tickets being checked?
- Is the concrete slump tested before pouring?
- Inspection Reports
- Are all previous inspection reports available and reviewed?
- Is there a record of any corrective actions taken?
10. Final Sign-Off
- Inspection Approval
- Has the pre-pour inspection been completed and approved?
- Are all identified issues resolved?
- Signatures
- Inspector’s Signature
- Contractor’s Signature
- Engineer’s Signature (if required)
Using eAuditor Audits & Inspection for this Checklist
- Create a Template: Open eAuditor Audits & Inspection and create a new template. Use the above checklist structure to add relevant sections, questions, and response options.
- Assign Actions: You can assign corrective actions directly within the checklist for any issues identified.
- Add Photos and Notes: eAuditor Audits & Inspection allows you to attach photos and notes to each item, which is useful for documenting specific conditions.
- Set Up Notifications: Set up notifications to alert relevant team members when an inspection is completed or if any issues are noted.
- Generate Reports: After completing the inspection, you can generate a report directly from eAuditor Audits & Inspection to share with the project team.
This checklist will ensure that all critical aspects of the pre-pour inspection are covered, helping to prevent issues during the concrete pour.
